2" Exit HF Drivers

Download Specification Sheet

SD-750N

The P Audio SD-750N is a state of the art high output compression driver. Advanced engineering and manufacturing methods have produced an extremely reliable and wide bandwidth device that also features very high fidelity.

Download Specification Sheet

GENERAL SPECIFICATIONS

  Type   Compression Driver
  Overall Diameter   135 mm/5.3 inch
  Throat Diameter   51 mm/2 inch
  Diaphragm Diameter   72.2 mm/2.84 inch
  Nominal Imedamce   8Ω
  Voice Coil DC Resistance   6.2Ω
  Power Handling   120 Watt
  Frequency Range (± 10 dB)   500Hz - 18kHz
  Sensitivity @ 1W 1M   110 dB
  Recommended Crossover   1kHz
  Mounting Type   Bolt On
  Magnet type   Neodymium 33SH Nikle
  Magnet size   135 x 82 x 9 (mm)
  Magnet weight   21.0 oz
  Diaphragm material   Titanium
  Diaphragm Colour   Metalic Silver
  Voice coil wire   ALR
  Voice coil former   NSV
  Cover material   Aluminium
  Cover colour   Black
  Gasket material   EVA
  Gasket colour   Black
  Packing Quantity   2 pcs.
  Packing dimension WxDxH   360 x 180 x 135 mm

SD-750N

The P Audio SD-750N is a state of the art high output compression driver. Advanced engineering and manufacturing methods have produced an extremely reliable and wide bandwidth device that also features very high fidelity.
